Home ProductsRotary PotentiometerRV12321GSKA Rotary 12mm Potentiometer Dual Unit Shaft Sealed With Switch

RV12321GSKA Rotary 12mm Potentiometer Dual Unit Shaft Sealed With Switch

RV12321GSKA Rotary 12mm Potentiometer Dual Unit Shaft Sealed With Switch
RV12321GSKA Rotary 12mm Potentiometer Dual Unit Shaft Sealed With Switch
RV12321GSKA Rotary 12mm Potentiometer Dual Unit Shaft Sealed With Switch RV12321GSKA Rotary 12mm Potentiometer Dual Unit Shaft Sealed With Switch RV12321GSKA Rotary 12mm Potentiometer Dual Unit Shaft Sealed With Switch RV12321GSKA Rotary 12mm Potentiometer Dual Unit Shaft Sealed With Switch
Basic Information
Place of Origin: China
Brand Name: SANNI
Minimum Order Quantity: 2000PCS
Packaging Details: 2000PCS/BOX
Delivery Time: 25 Working days
Payment Terms: T/T
Supply Ability: 30000pcs/Month
Contact Now
Model NO.: RV12321GSKA Quantity: Duplex
Shape: Square Resistance Change Scale: Log Or Linear
Application: Audio Brand: Sanni
SMD Direction: Horizontal Units: 2
Switch Type: Rotary Transport Package: Carton Boxes
Specification: 12mm Trademark: SANNI
Origin: China Supply Ability: 10000PCS Per Month
Resistance: Variable Resistor Function For Resistance: Load Resistor
Installation: SMD Resistor Material: Carbon Film Resistor
Packaging: Throught Hole Type: Rotary Potentiometer
Samples: US$ 0/Piece 1 Piece(Min.Order) | Request Sample Customization: Available | Customized Request
Highlight:

Rotary 12mm Potentiometer

,

12mm Potentiometer Dual Unit

,

Switch dual shaft potentiometer

RV12321GSKA Rotary Potentiometer 12mm Dual Unit Shaft Sealed Potentiometer with Switch



Features of Rotary Potentiometer

Using plastic sealing structure, can effectively deal with wave welding.
Good sealing performance
Can be with positioning.
Push-pull switch or rotating switch can be chosen.
Shaft length and shape can be adjusted.
A variety of mounting methods for choice.

Application of Rotary Potentiometer

Rotary Potentiometer is mainly suitable for walkie-talkie, multimedia audio, automobile power amplifier and other electronic equipment, but also can use household appliances or medical equipment. It's main functions are: light intensity adjustment,volume adjustment, menu selection, speed adjustment, temperature adjustment, etc.

Specification of Rotary Potentiometer


1.Electrical Characteristics
Total resistance 100Ω-3MΩ
Total resistance tolerance 50Ω~10KΩ:±30%/10KΩ~500KΩ:±20%/500KΩ~2MΩ:±30%
Residual resistance R≤10KΩ: 10ΩMax./10KΩ<R>500KΩ:20ΩMax./R≥500KΩ Nominal total resistance of 0.1% or less
Rated Power 0.05W
Insulation resistance 100MΩ min. 250V DC
Voltage proof 250V AC for 1 minute
Maximum operation voltage 50V AC/10V DC
2.Mechanical Characteristics
Rotation stopper strength Min:4.0Kgf
Total rotation angle 300o±5o
Totational1 10-150gf.cm
Key push-pull strength Min:8Kgf
Terminal Strength 5N for 1 minute
3.Switch Characteristics
Switch Type SPST
Rated Power 1A 16V DC
Switch Torque 500gf.cm Max
Switch Angle 40o Max
Operating Life without load 15000 cycles 100mΩ Max
Operating life with load:as rating 15000 cycles 200mΩ Max
Initial contact resistance 100mΩ Max
Insulation resistance 100MΩ min. 250V DC
Voltage proof 300V AC for 1 minute
4.Environmental Performance
Operating temperature range -10oC to +70oC
Storage temperature range -40oC to +85oC
5.Welding heat reference
Reference for hand soldering 350oC±10oC/3+1S
Reference for dip soldering 260oC±5oC/10±1S



FAQ

• Q: Can I get sample from you?

• A: Yes, we can provide the free samples for your testing, please contact us for free and tell us which product you need.

• Q: Do you accept customization?

• A: Yes, customization is acceptable, please contact our sales staffs for consult.

• Q: Can you provide help for technical issues?

• A: Yes, we have more than 10 years of research and development in the electronic potentiometer industry. If you need technical help in the purchase process, please feel free to contact us.

RV12321GSKA 12mm Shaft Sealed Potentiometer with SwitchRV12321GSKA 12mm Shaft Sealed Potentiometer with SwitchRV12321GSKA 12mm Shaft Sealed Potentiometer with SwitchRV12321GSKA 12mm Shaft Sealed Potentiometer with SwitchRV12321GSKA 12mm Shaft Sealed Potentiometer with SwitchRV12321GSKA 12mm Shaft Sealed Potentiometer with Switch

Tag:

Switch dual shaft potentiometer

Horizontal Rotary Potentiometer

Rotary Potentiometer Round
