Home ProductsRotary PotentiometerWLC0401 Potentiometer Control Box for Car Amplifier Volume Control

WLC0401 Potentiometer Control Box for Car Amplifier Volume Control

WLC0401 Potentiometer Control Box for Car Amplifier Volume Control
WLC0401 Potentiometer Control Box for Car Amplifier Volume Control
WLC0401 Potentiometer Control Box for Car Amplifier Volume Control
Basic Information
Place of Origin: China
Brand Name: SANNI
Certification: ISO9001:2015
Model Number: WLC0401
Minimum Order Quantity: 500pcs
Price: USD1.0~1.5 per pc
Packaging Details: 100pcs per Carton box,
Delivery Time: 25 working days
Payment Terms: T/T
Supply Ability: 10000pcs per Month
Contact Now
Model NO.: WLC0401 Shape: Square
Resistance Change Scale: Log Or Linear Application: Car Amplifier
Brand: Sanni Transport Package: Carton Boxes
Trademark: SANNI Origin: China
Supply Ability: 10000PCS Per Month Resistance: Variable Resistor
Function For Resistance: Load Resistor Material: Carbon Film Resistor
Type: Rotary Potentiometer Samples: US$ 5/Piece 1 Piece(Min.Order) | Request Sample
Customization: Available | Customized Request
Highlight:

WLC0401 Potentiometer Control Box

,

Car Amplifier Potentiometer Control Box

,

Car Amplifier Volume Control Box

WLC0401 Potentiometer Control Box for Car Amplifier Volume Control

APPLICATION:

The WLC0401 is special designed as a volume control unit as car amplifier romote control module. The taper and resistance can be designed per customer request. Even outline design can be changed per customer's needs.

Product Description

  • Taper and gangs to be decided by customer's request.
  • Most suitable for car amplifier volume control
  •    Rohs compliant
  •    Seal type
  •    Structural diversification
  •    High Quality
  • Mechanical characteristics:
  •    Total rotational angle: 300°±5°
  •    Rotational torque: 10-150gf.cm CC:click torque:60-400gf.cm
  •    Rotational stopper strength: MIN:3Kgf
  •    Key Push-pull strength: MIN:8Kgf
  •    Key wobble: Max:0.6*L/20mmP-P
  •    Terminal strength: 5N for 1 minute
  • Operating life: 15000 cycles
  • Electrical characteristics
  • Total resistance: 101-305 (100Ω-3MΩ)
  • Total resistance tolerance:±20%
  • Residual resistance: R≤100KΩ 20Ωmax
  • 50KΩ≤R Nominal total
  • Rated power: 0.05W
  • Insulation resistance: 100KΩ min. 205V DC
  • Voltage proof: 300V AC for 1minute
  • Maximum operating voltage: 50V AC.10V DC
WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 0WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 1WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 2WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 3WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 4WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 5WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 6WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 7WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 8WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 9WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 10WLC0401 Potentiometer Control Box for Car Amplifier Volume Control 11
