WLC03001 Rotary Potentiometer Remote control Box for Car Amplifier, Taper and Resistance to be Customized

• Taper and gangs to be decided by customer's request.
• Most suitable for car amplifier volume control
• Use:Used for car amplifier, audio amplifier
•    Rohs compliant
•    Seal type
•    Small volume
•    Structural diversification
•    High Quality
• Mechanical characteristics:
•    Total rotational angle: 300°±5°
•    Rotational torque: 10-150gf.cm CC:click torque:60-400gf.cm
•    Rotational stopper strength: MIN:3Kgf
•    Key Push-pull strength: MIN:8Kgf
•    Key wobble: Max:0.6*L/20mmP-P
•    Terminal strength: 5N for 1 minute
• Electrical characteristics
•    Total resistance: 101-305 (100Ω-3MΩ)
•    Total resistance tolerance:10KΩ-100KΩ:±20% other:±30%
•    Residual resistance: R≤100KΩ 20Ωmax
•                  50KΩ≤R Nominal total
•                  resistance of 0.1% or less
•    Rated power: 0.05W
•    Insulation resistance: 100KΩ min. 205V DC
•    Voltage proof: 300V AC for 1minute
•    Maximum operating voltage: 50V AC.10V DC
• Operating life: 15000 cycles

FAQ:

• Q: What is the brand of this product?
  A: The brand name of this product is SANNI.
• Q: What is the model number of this product?
  A: The model number of this product is RV90X.
• Q: Where is this product manufactured?
  A: This product is manufactured in Dongguan, China.
• Q: What is the function of a rotary potentiometer?
  A: A rotary potentiometer is used to control the amount of electric current flowing through a circuit by varying the resistance.
• Q: How does this product differ from a regular potentiometer?
  A: A rotary potentiometer has a rotating mechanism, allowing for continuous adjustment of resistance, while a regular potentiometer has a fixed resistance value.
