Metal Shaft Sealed Rotary Potentiometer RV874ANS For Walkie Talkie System

Metal Shaft Sealed Rotary Potentiometer RV874ANS For Walkie Talkie System
Metal Shaft Sealed Rotary Potentiometer RV874ANS For Walkie Talkie System
Metal Shaft Sealed Rotary Potentiometer RV874ANS For Walkie Talkie System Metal Shaft Sealed Rotary Potentiometer RV874ANS For Walkie Talkie System Metal Shaft Sealed Rotary Potentiometer RV874ANS For Walkie Talkie System
Basic Information
Place of Origin: China
Brand Name: SANNI
Model Number: RV874ANS
Minimum Order Quantity: 2000PCS
Price: USD0.3~0.6 per pc
Packaging Details: 2000PCS/BOX
Delivery Time: 25 Working days
Payment Terms: T/T
Supply Ability: 30000pcs/Month
Contact Now
Model NO.: RV874ANS Application: Walkie Talkie, Communication System And Other Control
Body Material: ABS, PC Shaft Material: Metal
Shaft Type: Knurled/D Type/Solid/Customize Specification: 8mm
Resistor Material: Carbon Film Resistor Customization: Available | Customized Request
Highlight:

Metal Shaft Sealed Rotary Potentiometer

,

Walkie Talkie Rotary Potentiometer

RV874ANS Metal Shaft Sealed Rotary Potentiometer with Switch for Walkie Talkie System



Description of Rotary Potentiometer



The rotating potentiometer is an adjustable electrical resistor, which slides on the resistors by the brush, and obtains the output voltage associated with the input voltage in the circuit. It is mainly used for communication products, walkie-talkie, automobile power amplifier, multimedia audio, smart home, computer peripheral, etc.



Features of Rotary Potentiometer with Switch



Using plastic sealing structure, can effectively deal with wave welding.

Good sealing performance.

Rotating switch with clear click sound.

Shaft length and shape can be adjusted.

A variety of mounting methods for choice.



Product Specification



1.Electrical Characteristics
Total resistance 200Ω-2MΩ
Total resistance tolerance 200Ω~1KΩ:±30%/1KΩ~500KΩ:±20%/500KΩ~3MΩ:±30%
Residual resistance 20ΩMax.
Rated Power 0.05W
Insulation resistance 100MΩ min. 250V DC
Noise 100mV Max
Voltage proof 100V AC for 1 minute
Maximum operation voltage 50V AC/20V DC
2.Mechanical Characteristics
Rotation stopper strength Min:3Kgf
Total rotation angle 300o±5o
Totational torque 10-100gf.cm
Key push-pull strength Min:8Kgf 10s Min
Key Wobble Max: 0.6*L/20mm P-P
Terminal Strength 5N for 1 minute
3.Switch Characteristics
Switch Type SPST
Rated Power 0.1A 5V DC
Switch Torque 200~800gf.cm
Switch Angle 40o Max
Operating Life without load 15000 cycles 100mΩ Max
Operating life with load:as rating 15000 cycles 200mΩ Max
Initial contact resistance 100mΩ Max
Insulation resistance 100MΩ min. 250V DC
Voltage proof 300V AC for 1 minute
4.Environmental Performance
Operating temperature range -10oC to +70oC
Storage temperature range -40oC to +85oC
5.Welding heat reference
Manual Soldering 96.5 Sn/3.0 Ag/0.5 Cu Sold Wire or No-Clean Rosin Core Wire 280oC Max. For 3 Seconds
Wave Soldering 96.5 Sn/3.0 Ag/0.5 Cu Sold Wire or No-Clean Flux 260oC Max. For 5 Seconds



Application of Rotary Potentiometer



Rotary Potentiometer is mainly suitable for  walkie-talkie, communication products,automobile power amplifier,multimedia audio,  and other electronic equipment, but also can use for household appliances, medical equipment. It's main functions are: light intensity adjustment,volume adjustment, speed adjustment, menu selection, temperature adjustment, etc.





RV874ANS Shaft Sealed Rotary Potentiometer with SwitchRV874ANS Shaft Sealed Rotary Potentiometer with SwitchRV874ANS Shaft Sealed Rotary Potentiometer with SwitchRV874ANS Shaft Sealed Rotary Potentiometer with SwitchRV874ANS Shaft Sealed Rotary Potentiometer with SwitchRV874ANS Shaft Sealed Rotary Potentiometer with Switch
