Dual Unit Dealed Shaft Absolute Rotary Encoder For Interphone Walkie-Talkie

Basic Information
Place of Origin: China
Brand Name: SANNI
Model Number: RE814BO
Minimum Order Quantity: 2000PCS
Packaging Details: 2000PCS/BOX
Delivery Time: 25 Working days
Payment Terms: T/T
Supply Ability: 30000pcs/Month
Bit: 16 Transport Package: Carton Box
Specification: 10mm Origin: China
Type: Rotary Encoder Working Principle: Absolute
Operating System: Contact Brush Type Signal Output: Long Drive Output
High Light:

Absolute Rotary Encoder Dual Unit

,

Walkie Talkie Absolute Rotary Encoder

Dual-Unit Dealed Shaft Encoder for Interphone&Walkie-Talkie



Description



Absolute encoder has many light channels on the light encode disk, each line in order with 2,4,8,16 lines... arrangement, so that in every position of the encoder, by reading the open and dark of each line, get a set of unique 2 zero code to 2 (Gray code), which is called n-bit absolute encoder. Such an encoder is determined by the mechanical position of the photoelectric code plate, which is not affected by power off and interference.



Dual Unit Dealed Shaft Absolute Rotary Encoder For Interphone Walkie-Talkie 0

Specification



Switch Performance
Circuit number: SPST
Rated power: 1A 16V DC
Switch Torque: 500gf.cm max
Switch Angle: 40º max
Operating life without load: 30,000 cycles 100mΩ max
Operating life with load: 30,000 cycles 200mΩ max
Initial contact resistance: 100mΩ max
Insulation resistance : 100mΩ min.250V DC
Voltage proof: 300V AC for 1 minute
Mechanical characteristics
Total rotational angel: 300°±5º
Detent: 16
Rotational torque: 150~350gf.cm
Rotational stopper strength : 3Kgf.max/Alu; 3.5kgf max/Brass; 4.0kgf max/Stainless steel
Shaft push-pull strength: 8Kgf.max
Rotational torque: 20~200f.cm CC: click torque: 60~400gf.cm
Shaft wobble: Max:0.6*L/20mm P-P max
Vibration: 10 to 50 to 10 Hz/min. the amplitude is 1.5mm for all the frequencies.
Electrical Performance
Number of pulse/detent 16/16
Features: with push switch/rotary switch
Insulation resistance : 100mΩ min.250V DC
Voltage proof: 300V AC for 1 minute
Durability
Operating life without load: 20,000 cycles 100mΩ max
Environmental performance
Cold: -40ºC±2ºC for 96h
Dry heat: 85ºC±2ºC for 96h
Damp heat: 40±2ºC, 90 to 95%RH for 96H





Features



1. Sealed design encoder with highly reliable performance.

2. Available in many different variants.

3. Push switch with 0.5mm travel or 1.5mm travel.

4. Shaft length and shape can be adjusted.





Application



Absolute rotary encoder, because of its absolute unique, anti-interference, no power loss memory, has been increasingly widely used in the Angle, length measurement and positioning control in various industrial systems.

It is mainly suitable for automotive electronics, household appliances. Household appliances like ovens and washing machines, audio products, timers and other related electronic devices.
