Horizontal Type Rotary Absolute Encoder Metal Shaft For Walkie Talkie Channel Controls

Basic Information
Place of Origin: China
Brand Name: SANNI
Model Number: RE81AF0
Minimum Order Quantity: 2000PCS
Packaging Details: 2000PCS/BOX
Delivery Time: 25 Working days
Payment Terms: T/T
Supply Ability: 30000pcs/Month
Package: SMD Brand: Sanni
Shaft Material: Metal Specification: 8MM
Trademark: SANNI Origin: Dongguan
Type: Rotary Encoder Signal Output: Long Drive Output
High Light:

Horizontal Rotary Absolute Encoder

,

Rotary Absolute Encoder Metal Shaft

,

Walkie Talkie Rotary Absolute Encoder

​Rotary Absolute Encoder Horizontal Type Metal Shaft for Walkie-Talkie Channel Controls







Description



Absolute encoder has many light channels on the light encode disk, each line in order with 2,4,8,16 lines... arrangement, so that in every position of the encoder, by reading the open and dark of each line, get a set of unique 2 zero code to 2 (Gray code), which is called n-bit absolute encoder. Such an encoder is determined by the mechanical position of the photoelectric code plate, which is not affected by power off and interference.

Horizontal Type Rotary Absolute Encoder Metal Shaft For Walkie Talkie Channel Controls 0



Specification



Switch Performance
Circuit number: SPST
Rated power: 1A 16V DC
Switch Torque: 500gf.cm max
Switch Angle: 40º max
Operating life without load: 30,000 cycles 100mΩ max
Operating life with load: 30,000 cycles 200mΩ max
Initial contact resistance: 100mΩ max
Insulation resistance : 100mΩ min.250V DC
Voltage proof: 300V AC for 1 minute
Mechanical characteristics
Total rotational angel: 300°±5º
Detent: 16
Rotational torque: 150~350gf.cm
Rotational stopper strength : 3Kgf.max/Alu; 3.5kgf max/Brass; 4.0kgf max/Stainless steel
Shaft push-pull strength: 8Kgf.max
Rotational torque: 20~200f.cm CC: click torque: 60~400gf.cm
Shaft wobble: Max:0.6*L/20mm P-P max
Vibration: 10 to 50 to 10 Hz/min. the amplitude is 1.5mm for all the frequencies.
Electrical Performance
Number of pulse/detent 16/16
Features: with push switch/rotary switch
Insulation resistance : 100mΩ min.250V DC
Durability
Operating life without load: 20,000 cycles 100mΩ max
Environmental performance
Cold: -40ºC±2ºC for 96h
Dry heat: 85ºC±2ºC for 96h
Damp heat: 40±2ºC, 90 to 95%RH for 96H





Features



1. Sealed design encoder with highly reliable performance.

2. Available in many different variants.

3. Push switch with 0.5mm travel or 1.5mm travel.

4. Shaft length and shape can be adjusted.

5. A variety of mounting methods for choice





Application



Absolute rotary photoelectric encoder, because of its absolute unique, anti-interference, no power loss memory, has been increasingly widely used in the Angle, length measurement and positioning control in various industrial systems

It is mainly suitable for automotive electronics, household appliances. Household appliances like ovens and washing machines, audio products, timers and other related electronic devices;

Mainly used to adjust the volume, temperature, frequency and function switching





Our Factory



Dongguan SANNI Electronics Technology Co., Ltd. have more than 10year of experiences in design and manufacture of potentiometer, encoder, switches and other electronics components. Factory covers 1,2000 square meters facility areas with 180+ employees. We have professinal and good technical and sales teams to serve your needs.





Our Advantage



1. 4 automation production lines, more than 100 experienced workers for higher precision products.

2. 10+ dedicated and experienced engineers and designers in R&D department.

3. Support ODM/OEM customized service. Help customers quickly design their ideas into mass production solutions, and complete prototype design, development and verification.

4. Professional Testing instruments and team to ensure product quality.





Our Services



1. Offer 1 year warranty

2. OEM/ODM service to meet all your needs

3. within 24 hours to reply your inquiries

4. Strong R&D team for technical support

5. Offer free sample for test





FAQ



• Q: Can I get sample from you?

• A: Yes, we can provide the free samples for your testing, please contact us for free and tell us which product you need.

• Q: Do you accept customization?

• A: Yes, customization is acceptable, please contact our sales staffs for consult.

• Q: Can you provide help for technical issues?

• A: Yes, we have more than 10 years of research and development in the electronic potentiometer industry. If you need technical help in the purchase process, please feel free to contact us.
