Incremental Digital Rotary Encoder With Push Switch Button For Automatic Instruments

Basic Information
Place of Origin: China
Brand Name: SANNI
Model Number: RE814AM
Minimum Order Quantity: 2000PCS
Packaging Details: 2000PCS/BOX
Delivery Time: 25 Working days
Payment Terms: T/T
Supply Ability: 30000pcs/Month
Installation Form: Axle Sleeve Type Axonia: Servo Installation Type
Bit: 20 Transport Package: Carton Box
Trademark: SANNI Origin: China
Working Principle: Incremental Readout Mode: Contact
Operating System: Contact Brush Type Axle Sleeve Type: Empty Type
High Light:

Incremental Rotary Encoder With Push Switch

,

Digital rotary encoder push button switch

,

rotary encoder push button switch

Digital Incremental Rotary Encoder with Push Switch for Automatic Instruments



Description





An incremental encoder is a type of encoder device that converts angular motion or position of a shaft into an analog or digital code to identify position or motion. Incremental encoders are one of the most commonly used rotary encoders. It provides excellent speed and distance feedback and, since there are few sensors involved, the systems are both simple and inexpensive. An incremental encoder is limited by only providing change information, so the encoder requires a reference device to calculate motion.





Specification



Switch Performance
Circuit number: PUSH
Rated power: 0.1A 5V DC
Switch Torque: 500± 200gf.cm max
Switch Angle: 0.5± 0.3
Operating life without load: 100,000 cycles 100mΩ max
Operating life with load: 100,000 cycles 200mΩ max
Initial contact resistance: 100mΩ max
Insulation resistance : 100mΩ min.250V DC
Voltage proof: 300V AC for 1 minute
Mechanical characteristics
Stopper strength 3kgf.max
Detent: 20
Rotational torque: 20~200gf.cm
Rotational stopper strength : 3Kgf.max/Alu; 3.5kgf max/Brass; 4.0kgf max/Stainless steel
push-pull strength: 8Kgf.max
Vibration: 10 to 50 to 10 Hz/min. the amplitude is 1.5mm for all the frequencies.
Electrical Performance
Number of pulse/detent 10/20
Features: with push switch/rotary switch
Insulation resistance : 100mΩ min.250V DC
Voltage proof: 300V AC for 1 minute
Center-taps: with
Environmental performance
Cold: -40ºC±2ºC for 96h
Dry heat: 85ºC±2ºC for 96h
Damp heat: 40±2ºC, 90 to 95%RH for 96H





Features



1. Sealed design encoder with highly reliable performance.

2. Available in many different variants.

3. Push switch with 0.5mm travel or 1.5mm travel.

4. Shaft length and shape can be adjusted.

5. A variety of mounting methods for choice

6. ROHS Compliant

7. Small Volume





Application



Incremental encoder is mainly used to measure speed, acceleration, rotation direction, Angle and so on. Widely used in walking machinery, CNC machine tools, elevator, servo motor, flow meter, textile machinery, metallurgical machinery, injection machinery, printing and packaging machinery, automatic instruments and other industrial automation measurement and control field.

Heavy Duty: demanding environment with a high probability of contaminants and moisture, higher temperature, shock, and vibration requirements as seen in pulp, paper, steel, and wood mills.





Our Factory



Dongguan SANNI Electronics Technology Co., Ltd. have more than 10year of experiences in design and manufacture of potentiometer, encoder, switches and other electronics components. Factory covers 1,2000 square meters facility areas with 180+ employees. We have professinal and good technical and sales teams to serve your needs.





Our Advantage



1. 4 automation production lines, more than 100 experienced workers for higher precision products.

2. 10+ dedicated and experienced engineers and designers in R&D department.

3. Support ODM/OEM customized service. Help customers quickly design their ideas into mass production solutions, and complete prototype design, development and verification.

4. Professional Testing instruments and team to ensure product quality.





Our Services



1. Offer 1 year warranty

2. OEM/ODM service to meet all your needs

3. within 24 hours to reply your inquiries

4. Strong R&D team for technical support

5. Offer free sample for test





FAQ



• Q: Can I get sample from you?

• A: Yes, we can provide the free samples for your testing, please contact us for free and tell us which product you need.

• Q: Do you accept customization?

• A: Yes, customization is acceptable, please contact our sales staffs for consult.

• Q: Can you provide help for technical issues?

• A: Yes, we have more than 10 years of research and development in the electronic potentiometer industry. If you need technical help in the purchase process, please feel free to contact us.
