Name: SF17030 Mini Electric Guitar Footswitch With Spring Actuator Lever Drive
Brand: Dongguan SANNI Electronics Technology Co., Ltd.
SKU: SF17030
Price: 0.60 USD
Availability: InStock

SF17030 Mini Electric Guitar Footswitch With Spring Actuator Lever Drive

Basic Information

Place of Origin:	China
Brand Name:	SANNI
Model Number:	SF17030

Minimum Order Quantity:	1000pcs
Price:	USD0.6 -0.9per pc
Packaging Details:	500pcs per Carton box,
Delivery Time:	25 working days
Payment Terms:	T/T
Supply Ability:	10000pcs per Month

Contact Now

Model NO.:	SF17030	Trademark:	SANNI
Material:	Steel, Brass Or Stainless Steel	Specification:	17mm
Usage:	Musical Instruments, Industrial Control, And Others	Structure:	Screw Shank
Samples:	Free Sample With Freight Collect Shipping	Customization:	Available \| Customized Request
Highlight:	Mini Electric Guitar Footswitch , Lever Drive Electric Guitar Footswitch

SF17030 Guitar Pedal Footswitch Spring Actuator Lever Drive For Mini Switch

Product Description

RoHS Compliant
Spring Actuator
Vertical Mounting
Spring Guid Sleeve to lead the Spring Push Direction Straightly
Function:Intacts on to the Button of the tact switch.
Durable Structure

Product Specification

Spring Force	650+/-200 gf.cm or customize
Withstand Voltage	1000V AC-1 minute
Rating	125V AC 6A, 250V AC 3A, 30V DC 4A
Insulation Resistance	500V DC- 100MΩ Min
Contact Resistance	50mΩ Max
Operating Life	15,000 cycles

What is a Spring Actuator for Pedal?

Spring actuator is a type of mechanical drive used for guitar and/or bass effects pedals. It is installed on the pedal body and the spring push on a tact switch. As a result, it performs normal drive function without transferring unnecessary mechanical stress to the switch.
